mmaxDrawdown

mmaxDrawdown(X, window, [ratio=true], [minPeriods])

Alias: mmdd

Calculates the moving maximum drawdown or moving maximum drawdown rate. NULL values are ignored in the calculation.

X is a numeric vector, matrix, or table that specifies the data used to calculate the maximum drawdown. It typically contains cumulative returns or rates of return.

window is a positive integer or a DURATION scalar.

• If window is a positive integer, it specifies the moving window length measured by the number of elements.
• If window is a DURATION, it specifies the moving window length measured by time. In this case, X must be an indexed matrix or indexed series with a temporal row index.

ratio is a Boolean scalar that specifies whether to return the maximum drawdown rate. The default value is true.

• If true, returns the maximum drawdown rate, which is the maximum percentage decline relative to the peak. The formula is:



• If false, returns the maximum drawdown based on the absolute decline amount. The formula is:



minPeriods is a positive integer that specifies the minimum number of non-NULL elements required in the moving window. If the number of non-NULL elements in the moving window is less than minPeriods, the result for that window is NULL. The default value is the same as window. If window is a DURATION and minPeriods must be set, minPeriods must be 1.

A DOUBLE value with the same form as the input data X.

Example 1: Store the cumulative returns of a portfolio in an in-memory table, and calculate the moving maximum drawdown of the cumulative returns over a 3-day window.

// Create an in-memory table to record the cumulative returns of a portfolio over 8 consecutive days
t = table(2024.10.01 + 0..7 as date, [36, 96, 42, 100, 59, 86, 25, 72] as cumReturn)

// Calculate the moving maximum drawdown of the portfolio's cumulative returns over a 3-day window
select date, cumReturn as MDD_in_3days from mmaxDrawdown(t, 3, false)

Example 2: Store the cumulative returns of a portfolio in an indexed matrix, and calculate the moving maximum drawdown rate of the cumulative returns over a 3-day window.

// Create an indexed matrix to record the cumulative returns of a portfolio over 8 consecutive days
m = matrix(1..8, 36 96 42 100 59 86 25 72)
m.rename!(2024.10.01..2024.10.08, `No.`cumReturn)
m.setIndexedMatrix!()

// Calculate the moving maximum drawdown rate of the portfolio's cumulative returns over a 3-day window.
// The result is a matrix. Use the col function to retrieve the result vector.
round(mmaxDrawdown(m,3d,true).col(1), 2)
// Output: [0,0,0.56,0.56,0.41,0.41,0.71,0.71]

Example 3: Simulate market data for CSI 300 stocks and calculate the 5-day moving maximum drawdown rate.

// Set the stocks and observation dates for simulation.
securities = `600519.SH`000858.SZ`601318.SH`600036.SH`000333.SZ
n = 10
dates = 2024.01.02 + 0..(n - 1)
// Simulate closing prices.
stockInfo = table(securities as securityID)
dateInfo = table(dates as tradeDate)
price = cj(stockInfo, dateInfo)
price[`close] = round(100 + rand(20.0, size(securities) * n), 2)
price = select * from price order by securityID, tradeDate
// Calculate the 5-day moving maximum drawdown rate for each stock.
result = select tradeDate,
 securityID,
 close,
 round(mmaxDrawdown(close, 5, true), 4) as mdd5
from price
context by securityID
select * from result where tradeDate >= 2024.01.08

Because close is generated from random numbers, the prices and drawdown rates differ each time the script runs. A sample of the output is shown below:

Related function: maxDrawdown
