Functional Programming Cases

In the following example, we’ll use a sample CSV file named candle_201801.csv, with data like the following:

symbol,exchange,cycle,tradingDay,date,time,open,high,low,close,volume,turnover,unixTime
000001,SZSE,1,20180102,20180102,93100000,13.35,13.39,13.35,13.38,2003635,26785576.72,1514856660000
000001,SZSE,1,20180102,20180102,93200000,13.37,13.38,13.33,13.33,867181
......

(1)Create the Database

Create a database VALUE partitioned on dates:

login(`admin,`123456)
dataFilePath="/home/data/candle_201801.csv"
dbPath="dfs://DolphinDBdatabase"
db=database(dbPath,VALUE,2018.01.02..2018.01.30)

(2)Create the Table

First, use the extractTextSchema function to infer the table schema from the CSV file. The “time” column is recognized as INT type. To store it as TIME, use an UPDATE statement to change its type in the schema, and then use this modified schema to create a partitioned table (partitioned by the “date” column).

schemaTB=extractTextSchema(dataFilePath)
update schemaTB set type="TIME" where name="time"
tb=table(1:0, schemaTB.name, schemaTB.type)
tb=db.createPartitionedTable(tb, `tb1, `date);

Note: Instead of using extractTextSchema, you may also define the schema manually.

(3) Importing the Data

First define a transformation function i2t to preprocess the “time” column, converting it from INT to TIME type. This function is then passed to loadTextEx using the transform parameter so the conversion happens automatically during import.

def i2t(mutable t){
    return t.replaceColumn!(`time, t.time.format("000000000").temporalParse("HHmmssSSS"))
}

Note: When modifying data inside a function, use in-place operations (functions ending with !) to boost performance.

Import the data using:

tmpTB=loadTextEx(dbHandle=db, tableName=`tb1, partitionColumns=`date, filename=dataFilePath, transform=i2t);

(4) Querying the data

To verify the results, check the first two rows:

select top 2 * from loadTable(dbPath,`tb1);

symbol exchange cycle tradingDay date       time               open  high  low   close volume  turnover   unixTime
------ -------- ----- ---------- ---------- --------------     ----- ----- ----- ----- ------- ---------- -------------
000001 SZSE     1     2018.01.02 2018.01.02 09:31:00.000       13.35 13.39 13.35 13.38 2003635 2.678558E7 1514856660000
000001 SZSE     1     2018.01.02 2018.01.02 09:32:00.000       13.37 13.38 13.33 13.33 867181  1.158757E7 1514856720000

Complete Code

login(`admin,`123456)
dataFilePath="/home/data/candle_201801.csv"
dbPath="dfs://DolphinDBdatabase"
db=database(dbPath,VALUE,2018.01.02..2018.01.30)
schemaTB=extractTextSchema(dataFilePath)
update schemaTB set type="TIME" where name="time"
tb=table(1:0,schemaTB.name,schemaTB.type)
tb=db.createPartitionedTable(tb,`tb1,`date);

def i2t(mutable t){
    return t.replaceColumn!(`time,t.time.format("000000000").temporalParse("HHmmssSSS"))
}

tmpTB=loadTextEx(dbHandle=db,tableName=`tb1,partitionColumns=`date,filename=dataFilePath,transform=i2t);

In this example, we'll import data where nanosecond timestamps are stored as integers, and convert them into the NANOTIMESTAMP type. The example uses a text file named nx.txt, with sample data like this:

SendingTimeInNano#securityID#origSendingTimeInNano#bidSize
1579510735948574000#27522#1575277200049000000#1
1579510735948606000#27522#1575277200049000000#2
...

Each line uses # as the delimiter. The “SendingTimeInNano” and “origSendingTimeInNano” columns contain timestamps in nanosecond format.

(1) Creating the Database and Table

We start by defining a COMPO-partitioned DFS database db, and table nx with specified column names and types:

dbSendingTimeInNano = database(, VALUE, 2020.01.20..2020.02.22);
dbSecurityIDRange = database(, RANGE,  0..10001);
db = database("dfs://testdb", COMPO, [dbSendingTimeInNano, dbSecurityIDRange]);

nameCol = `SendingTimeInNano`securityID`origSendingTimeInNano`bidSize;
typeCol = [`NANOTIMESTAMP,`INT,`NANOTIMESTAMP,`INT];
schemaTb = table(1:0,nameCol,typeCol);

db = database("dfs://testdb");
nx = db.createPartitionedTable(schemaTb, `nx, `SendingTimeInNano`securityID);

(2) Importing the Data

To import the data, we define a transformation function that converts integer timestamps into the NANOTIMESTAMP type using the nanotimestamp function:

def dataTransform(mutable t){
  return t.replaceColumn!(`SendingTimeInNano, nanotimestamp(t.SendingTimeInNano)).replaceColumn!(`origSendingTimeInNano, nanotimestamp(t.origSendingTimeInNano))
}

Finally, we use loadTextEx to import the data.

Complete Code

dbSendingTimeInNano = database(, VALUE, 2020.01.20..2020.02.22);
dbSecurityIDRange = database(, RANGE,  0..10001);
db = database("dfs://testdb", COMPO, [dbSendingTimeInNano, dbSecurityIDRange]);

nameCol = `SendingTimeInNano`securityID`origSendingTimeInNano`bidSize;
typeCol = [`NANOTIMESTAMP,`INT,`NANOTIMESTAMP,`INT];
schemaTb = table(1:0,nameCol,typeCol);

db = database("dfs://testdb");
nx = db.createPartitionedTable(schemaTb, `nx, `SendingTimeInNano`securityID);

def dataTransform(mutable t){
  return t.replaceColumn!(`SendingTimeInNano, nanotimestamp(t.SendingTimeInNano)).replaceColumn!(`origSendingTimeInNano, nanotimestamp(t.origSendingTimeInNano))
}

pt=loadTextEx(dbHandle=db,tableName=`nx , partitionColumns=`SendingTimeInNano`securityID,filename="nx.txt",delimiter='#',transform=dataTransform);

For more on text file importing, see user manual.

In some scenarios, we may need to apply a function to every element within a given parameter. Without functional programming, this often requires a for loop. DolphinDB offers higher-order functions such as each, peach, loop, and ploop, which simplify the code significantly.

The higher-order functions loop and each are similar, but they differ in the format and type of their return values.

The each function determines the data form of its return based on the type and form of the result from each subtask:

• If each subtask returns a scalar, each returns a vector.
• If each subtask returns a vector, each returns a matrix.
• If each subtask returns a dictionary, each returns a table.
• If the return types or forms of the subtasks vary, each returns a tuple; otherwise, it returns a vector or matrix as appropriate.

For example:

m=1..12$4:3;
m;
each(add{1 2 3 4}, m);

This yields:

On the other hand, loop always returns a tuple. For instance, to calculate the maximum value of each column:

t = table(1 2 3 as id, 4 5 6 as value, `IBM`MSFT`GOOG as name);
t;
loop(max, t.values());

This yields:

Importing multiple files

Suppose we have multiple CSV files with the same structure stored in a directory, and we want to import them into a single in-memory table in DolphinDB. We can use loop to achieve this:

loop(loadText, fileDir + "/" + files(fileDir).filename).unionAll(false)

In this case, we first create a table t with two columns: sym and bidPrice:

t = table(take(`a`b`c`d`e ,100) as sym, rand(100.0,100) as bidPrice)

We want to perform the following calculations:

1. Compute a new column “ln”: This column stores the result of the following calculation: For each row, divide the current bidPrice by the average bidPrice of the previous 3 rows (excluding the current row), and then take the natural logarithm of the result.
2. Compute a new column “clean” based on “ln”: This column filters out abnormal values in “ln”. The logic is:
   1. Take the absolute value of “ln”.
   2. If it exceeds a fluctuation threshold F, then use the previous “ln” value instead. Otherwise, treat the current value as normal and keep it.

Since the computation of “ln“ involves a sliding window of size 3, we can refer to the example in section 3.4.1. The corresponding script is:

t2 = select *, log(bidPrice / prev(moving(avg, bidPrice,3))) as ln from t

However, for better performance, we can use built-in function mavg, which is more efficient than the moving higher-order function. The code can be rewritten in two equivalent ways:

//method 1
t2 = select *, log(bidPrice / prev(mavg(bidPrice,3))) as ln from t

//method 2
t22 = select *, log(bidPrice / mavg(prev(bidPrice),3)) as ln from t

Here, prev returns the data from the previous row.

Both approaches give equivalent results. The only difference is that in t22, a value is generated starting from the third row.

Now, to clean abnormal values in “ln”. Assuming the fluctuation threshold F is 0.02, we define a function cleanFun as follows:

F = 0.02
def cleanFun(F, x, y): iif(abs(x) > F, y, x)

• x is the current “ln” value.
• y is the previous “ln” value.
• If the absolute value of x exceeds F, the function returns y instead of x.

Then we use the high-order function eachPre to apply this logic pairwise across the column. The implementation of eachPre is equivalent to: F(X[0], pre), F(X[1], X[0]), ..., F(X[n], X[n-1]). The corresponding code:

t2[`clean] = eachPre(cleanFun{F}, t2[`ln])

Here is the complete script:

F = 0.02
t = table(take(`a`b`c`d`e ,100) as sym, rand(100.0,100) as bidPrice)
t2 = select *, log(bidPrice / prev(mavg(bidPrice,3))) as ln from t
def cleanFun(F,x,y) : iif(abs(x) > F, y,x)
t2[`clean] = eachPre(cleanFun{F}, t2[`ln])

This example demonstrates how to find the index of the maximum value in each row of a matrix. First, we define a matrix m as follows:

a1 = 2 3 4
a2 = 1 2 3
a3 = 1 4 5
a4 = 5 3 2
m = matrix(a1,a2,a3,a4)

One approach is to calculate the index of the maximum value for each row individually. This can be done using the imax function. By default, imax operates on each column of a matrix and returns a vector.

To compute the result by row instead, we can first transpose the matrix and then apply imax:

imax(m.transpose())

Alternatively, DolphinDB provides a higher-order function byRow, which applies a specified function to each row of a matrix. This avoids the need to transpose the matrix:

byRow(imax, m)

The same operation can also be performed using the built-in row function rowImax:

print rowImax(m)

The segmentby function is a higher-order function used to apply a computation to segments of data, where each segment is defined by consecutive identical values in another vector. The high-order function segmentby has the following syntax:

segmentby(func, funcArgs, segment)

func specifies the operation to perform on each segment, funcArgs provides the data to be processed, and segment determines how the data is divided into groups. When consecutive elements in segment have the same value, they form a single group. Each group of values from funcArgs is processed independently by func, and the results are combined to produce an output vector with the same length as the original segment vector.

x = 1 2 3 0 3 2 1 4 5
y = 1 1 1 -1 -1 -1 1 1 1
segmentby(cumsum, x, y)

In the above example, y defines three groups: 1 1 1, -1 -1 -1, and 1 1 1. Based on this grouping, x is divided accordingly into: 1 2 3, 0 3 2, and 1 4 5. The cumsum function is then applied to each group of x, computing the cumulative sum within each segment.

DolphinDB also provides the built-in segment function, which is used for grouping in SQL queries. Unlike segmentby, it only returns group identifiers without performing calculations.

The following example shows how to group data based on a threshold value. Continuous values that are either above or below the threshold are grouped together. For groups where values exceed the threshold, we retain only the record with the maximum value within each group (if there are duplicates, only the first is kept).

Given the table below, when the threshold is set to 0.3,the rows indicated by arrows should be kept:

Define the table:

dated = 2021.09.01..2021.09.12
v = 0 0 0.3 0.3 0 0.5 0.3 0.7 0 0 0.3 0
t = table(dated as date, v)

To group the data based on whether values are continuously greater than minV, use the segment function:

segment(v >= minV)

In SQL, we can combine segment with the CONTEXT BY clause to perform group calculations. Then, filter for groups with the maximum value using the HAVING clause. Since filtering might return multiple rows, use the LIMIT clause to keep only the first matching record per group.

Here is the complete SQL query:

select * from t
context by segment(v >= minV)
having (v = max(v) and v >= minV)
limit 1

The high-order function pivot reorganizes data along two specified dimensions and returns the result as a matrix.

Suppose we have a table t1 with four columns:

syms=`600300`600400`600500$SYMBOL
sym=syms[0 0 0 0 0 0 0 1 1 1 1 1 1 1 2 2 2 2 2 2 2]
time=09:40:00+1 30 65 90 130 185 195 10 40 90 140 160 190 200 5 45 80 140 170 190 210
price=172.12 170.32 172.25 172.55 175.1 174.85 174.5 36.45 36.15 36.3 35.9 36.5 37.15 36.9 40.1 40.2 40.25 40.15 40.1 40.05 39.95
volume=100 * 10 3 7 8 25 6 10 4 5 1 2 8 6 10 2 2 5 5 4 4 3
t1=table(sym, time, price, volume);
t1;

We want to reorganize the data in t1 by the columns “time” (at the minute level) and “sym”, and compute the volume-weighted average price (VWAP) for each stock per minute.

To do this, we use the pivot function:

stockprice = pivot(wavg, [t1.price, t1.volume], minute(t1.time), t1.sym)
stockprice.round(2)

The higher-order function contextby groups data based on specified column(s) and applies a given function within each group.

Example:

sym = `IBM`IBM`IBM`MS`MS`MS
price = 172.12 170.32 175.25 26.46 31.45 29.43
qty = 5800 700 9000 6300 2100 5300
trade_date = 2013.05.08 2013.05.06 2013.05.07 2013.05.08 2013.05.06 2013.05.07
contextby(avg, price, sym)

The contextby function can also be used in SQL queries. For example, the following query uses contextby to select trades where the price is above the group average:

t1 = table(trade_date, sym, qty, price)
select trade_date, sym, qty, price from t1 where price > contextby(avg, price, sym)

When we need to apply different functions to the same set of inputs in batch, we can use the higher-order functions call/unifiedCall together with each/ loop.

In the example below, the call function is used within a partial application to apply the functions sin and log to a fixed vector [1, 2, 3] using the higher-order function each:

each(call{, 1..3}, (sin, log));

Functions can also be invoked dynamically using metaprogramming with funcByName. The previous example can be rewritten as:

each(call{, 1..3}, (funcByName("sin"), funcByName("log")));

each(eval, each(makeCall{, 1..3}, (sin, log)));

Given minute-level trading data, the goal is to split the data for a stock into segments such that each segment contains approximately 1.5 million shares traded. The length of each time window will vary depending on how many trading records are needed to reach this volume. The rule for segmentation is: if adding the current data point brings the total volume closer to the 1.5 million share target, include it in the current segment; otherwise, begin a new segment starting from that point.

Generate a sample dataset:

timex = 13:03:00+(0..27)*60
volume = 288658 234804 182714 371986 265882 174778 153657 201388 175937 138388 169086 203013 261230 398871 692212 494300 581400 348160 250354 220064 218116 458865 673619 477386 454563 622870 458177 880992
t = table(timex as time, volume)

We define a grouping function to accumulate volume and split segments when the cumulative volume gets closest to 1.5 million:

def caclCumVol(target, preResult, x){
 result = preResult + x
 if(result - target> target - preResult) return x
 else return result
}
accumulate(caclCumVol{1500000}, volume)

caclCumVol accumulates the volume values and segments the data when the cumulative sum approaches 1.5 million most closely. A new group starts from the next value.

To identify the start of each group, we compare the accumulated volume with the original volume values. If they are equal, that point marks the start of a new group. We then use ffill() to forward-fill these start times:

iif(accumulate(caclCumVol{1500000}, volume) == volume, timex, NULL).ffill()

Finally, we group the data by these start times and perform aggregations.

output = select
    sum(volume) as sum_volume,
    last(time) as endTime
from t
group by iif(accumulate(caclCumVol{1500000}, volume) == volume, time, NULL).ffill() as startTime

Complete Script:

timex = 13:03:00+(0..27)*60
volume = 288658 234804 182714 371986 265882 174778 153657 201388 175937 138388 169086 203013 261230 398871 692212 494300 581400 348160 250354 220064 218116 458865 673619 477386 454563 622870 458177 880992
t = table(timex as time, volume)

def caclCumVol(target, preResult, x){
 result = preResult + x
 if(result - target> target - preResult) return x
 else return result
}
output = select sum(volume) as sum_volume, last(time) as endTime from t group by iif(accumulate(caclCumVol{1500000}, volume)==volume, time, NULL).ffill() as startTime

This example demonstrates how to use the window function to process a column in a table. The goal is to determine whether a given value is the minimum within both its preceding 5 values and following 5 values (both including itself). If it is, mark it as 1; otherwise, mark it as 0.

First, create a table t:

t = table(rand(1..100,20) as id)

Next, apply the window function to define a sliding window of 9 elements centered on each row (4 before, the current one, and 4 after). Within this window, use the min function to find the minimum value. Note: The window function includes the boundary values in the window range.

The implementation is as follows:

select *, iif(id==window(min, id, -4:4), 1, 0) as mid from t

Some of the previous examples also made use of the higher-order function reduce. Here's the pseudocode for it:

result = <function>(init, X[0])
for (i = 1 to size(X) - 1) {
  result = <function>(result, X[i])
}
return result

Unlike accumulate, which returns all intermediate results, reduce only returns the final result.

For example, in the following factorial calculation:

r1 = reduce(mul, 1..10)
r2 = accumulate(mul, 1..10)[9]

Both r1 and r2 produce the same final result.

Suppose we need to set up a scheduled job that runs daily at midnight to calculate the maximum temperature recorded by a specific device on the previous day.

Assume that the temperature data is stored in a table named “sensor” located in the distributed database dfs://dolphindb. The table contains a timestamp column ts of type DATETIME. The following script defines a function getMaxTemperature to perform the required calculation:

def getMaxTemperature(deviceID){
    maxTemp=exec max(temperature) from loadTable("dfs://dolphindb","sensor")
            where ID=deviceID ,date(ts) = today()-1
    return  maxTemp
}

Once the function is defined, we can use the scheduleJob function to submit the scheduled job. However, since scheduleJob does not allow passing arguments to the job function directly—and getMaxTemperature requires the deviceID as a parameter—we can use partial application to bind the argument in advance, effectively turning it into a no-argument function:

scheduleJob(`testJob, "getMaxTemperature", getMaxTemperature{1}, 00:00m, today(), today()+30, 'D');

This example schedules the job to calculate the maximum temperature for device ID 1.

The complete script looks like this:

def getMaxTemperature(deviceID){
    maxTemp=exec max(temperature) from loadTable("dfs://dolphindb","sensor")
            where ID=deviceID ,date(ts) = today()-1
    return  maxTemp
}

scheduleJob(`testJob, "getMaxTemperature", getMaxTemperature{1}, 00:00m, today(), today()+30, 'D');

In DolphinDB, after submitting scheduled jobs, we can use the getRecentJobs function to check the status of recent batch jobs (including scheduled jobs) on the local node. For example, to view the statuses of the three most recent batch jobs on the local node, use the following script:

getRecentJobs(3);

To retrieve job information from other nodes in the cluster, use the rpc function to call getRecentJobs on the remote node. For example, to get job information from the node with the alias P1-node1, we can do the following:

rpc("P1-node1",getRecentJobs)

However, if we try to retrieve the three most recent jobs from P1-node1 using the following script, it will result in an error:

rpc("P1-node1",getRecentJobs(3))

This is because the second argument of the rpc function must be a function (either built-in or user-defined), not the result of a function call. To work around this, we can use partial application to bind the argument to getRecentJobs, creating a new function that can be passed to rpc:

rpc("P1-node1",getRecentJobs{3})

In stream computing, users typically need to define a message processing function that handles incoming messages. This function generally accepts a single argument (the incoming subscription data) or a table, making it challenging to maintain state between processing events.

However, partial application offers a solution to this limitation. The following example uses partial application to define a stateful message handler called cumulativeAverage, which calculates the cumulative average of incoming data.

We first define a stream table trades. For each incoming message, we calculate the average of the price column and output the result to the avgTable. Here's the script:

share streamTable(10000:0,`time`symbol`price, [TIMESTAMP,SYMBOL,DOUBLE]) as trades
avgT=table(10000:0,[`avg_price],[DOUBLE])

def cumulativeAverage(mutable avgTable, mutable stat, trade){
   newVals = exec price from trade;

   for(val in newVals) {
      stat[0] = (stat[0] * stat[1] + val )/(stat[1] + 1)
      stat[1] += 1
      insert into avgTable values(stat[0])
   }
}

subscribeTable(tableName="trades", actionName="action30", handler=cumulativeAverage{avgT,0.0 0.0}, msgAsTable=true)

In the user-defined function cumulativeAverage, avgTable is the output table that stores the results. stat is a vector holding two values: stat[0] stores the current cumulative average, and stat[1] keeps track of the count of processed values. The function updates these values as it processes each message and inserts the updated average into the output table.

When subscribing to the stream table, we use partial application to pre-bind the first two parameters (avgTable and stat), allowing us to create a “stateful” function.

The following example demonstrates how to use the mr (MapReduce) function to convert high-frequency tick data into minute-level data.

In DolphinDB, we can use a SQL query to aggregate tick data into minute-level data:

minuteQuotes = select avg(bid) as bid, avg(ofr) as ofr from t group by symbol, date, minute(time) as minute

This can also be achieved using DolphinDB’s distributed computing framework. The mr (MapReduce) function is a core feature of DolphinDB’s distributed computing framework.

Here is the full script:

login(`admin, `123456)
db = database("dfs://TAQ")
quotes = db.loadTable("quotes")

//create a new table quotes_minute
model=select  top 1 symbol,date, minute(time) as minute,bid,ofr from quotes where date=2007.08.01,symbol=`EBAY
if(existsTable("dfs://TAQ", "quotes_minute"))
db.dropTable("quotes_minute")
db.createPartitionedTable(model, "quotes_minute", `date`symbol)

//populate data for table quotes_minute
def saveMinuteQuote(t){
minuteQuotes=select avg(bid) as bid, avg(ofr) as ofr from t group by symbol,date,minute(time) as minute
loadTable("dfs://TAQ", "quotes_minute").append!(minuteQuotes)
return minuteQuotes.size()
}

ds = sqlDS(<select symbol,date,time,bid,ofr from quotes where date between 2007.08.01 : 2007.08.31>)
timer mr(ds, saveMinuteQuote, +)

Stateful factors rely not only on current data but also on historical data for their calculations. Calculating such factors generally involves the following steps:

1. Save the current batch of incoming messages.
2. Compute the factor using the updated historical data.
3. Write the computed factor to an output table.
4. Optionally, clean up historical data that will no longer be needed.

In DolphinDB, message processing functions must be unary—they can only take the current message as input. To preserve historical state and still compute factors within the message handler, partial application is used. This technique fixes some parameters (to store state) and leaves one open for incoming messages. These fixed parameters are contained only within that specific message handler function.

The historical state can be stored in in-memory tables, dictionaries, or in-memory partitioned tables. This example uses a dictionary to store quote data and compute a factor using DolphinDB's streaming engines. For implementations using memory or in-memory partitioned tables, refer to Calculating High Frequency Factors in Real-Time.

Defining the Factor: We define a factor that calculates the ratio between the current ask price (askPrice1) and the ask price from 30 quotes ago.

The corresponding function is:

defg factorAskPriceRatio(x){
	cnt = x.size()
	if(cnt < 31) return double()
	else return x[cnt - 1] / x[cnt - 31]
}

Once the data is loaded and the stream table is set up, we can simulate a real-time stream processing scenario using the replay function.

quotesData = loadText("/data/ddb/data/sampleQuotes.csv")

x = quotesData.schema().colDefs
share streamTable(100:0, x.name, x.typeString) as quotes1

Setting Up the Historical State: We use a dictionary to store historical ask prices keyed by stock symbol:

history = dict(STRING, ANY)

Each key is a stock symbol (STRING), and the value is a tuple containing the history of ask prices.

Message Handler: The message handler completes three key tasks: it updates the dictionary with the most recent ask price, calculates the factor for each unique stock symbol, and records the results in an output table.

Subscribe to the stream table and inject data into it using data replay. Each time a new record arrives, it triggers the factor calculation.

def factorHandler(mutable historyDict, mutable factors, msg){
	historyDict.dictUpdate!(
	    function=append!,
	    keys=msg.symbol,
	    parameters=msg.askPrice1,
	    initFunc=x->array(x.type(), 0, 512).append!(x)
	)

	syms = msg.symbol.distinct()
	cnt = syms.size()
	v = array(DOUBLE, cnt)

	for(i in 0:cnt){
	    v[i] = factorAskPriceRatio(historyDict[syms[i]])
	}

	factors.tableInsert([take(now(), cnt), syms, v])
}

“historyDict” stores the price history; “factors” is the output table for storing calculated results.

Full Example

quotesData = loadText("/data/ddb/data/sampleQuotes.csv")

defg factorAskPriceRatio(x){
	cnt = x.size()
	if(cnt < 31) return double()
	else return x[cnt - 1]/x[cnt - 31]
}
def factorHandler(mutable historyDict, mutable factors, msg){
	historyDict.dictUpdate!(function=append!, keys=msg.symbol, parameters=msg.askPrice1, initFunc=x->array(x.type(), 0, 512).append!(x))
	syms = msg.symbol.distinct()
	cnt = syms.size()
	v = array(DOUBLE, cnt)
	for(i in 0:cnt){
	    v[i] = factorAskPriceRatio(historyDict[syms[i]])
	}
	factors.tableInsert([take(now(), cnt), syms, v])
}

x=quotesData.schema().colDefs
share streamTable(100:0, x.name, x.typeString) as quotes1
history = dict(STRING, ANY)
share streamTable(100000:0, `timestamp`symbol`factor, [TIMESTAMP,SYMBOL,DOUBLE]) as factors
subscribeTable(tableName = "quotes1", offset=0, handler=factorHandler{history, factors}, msgAsTable=true, batchSize=3000, throttle=0.005)

replay(inputTables=quotesData, outputTables=quotes1, dateColumn=`date, timeColumn=`time)

View the results:

select top 10 * from factors where isValid(factor)

In the following example, we create a table “orders” that contains some simple stock order data:

orders = table(`IBM`IBM`IBM`GOOG as SecID, 1 2 3 4 as Value, 4 5 6 7 as Vol)

Next, we create a dictionary where the key is the stock symbol and the value is a subtable of “orders” that contains only the records for that particular stock.

The dictionary is defined as:

historyDict = dict(STRING, ANY)

Then, we use the dictUpdate! function to update the values for each key in the dictionary:

historyDict.dictUpdate!(function=def(x,y){tableInsert(x,y);return x}, keys=orders.SecID, parameters=orders, initFunc=def(x){t = table(100:0, x.keys(), each(type, x.values())); tableInsert(t, x); return t})

The dictUpdate! process can be understood as iterating over each row in parameters, using the specified function to update the dictionary based on the corresponding key defined by keys.

If a key does not yet exist in the dictionary, the system will call initFunc to initialize the value for that key.

In this example, the dictionary's key is the stock code, and the value is a sub-table of orders. We use orders.SecID as the keys. For the update logic, we define a lambda function to insert the current record into the corresponding table:

def(x,y){tableInsert(x,y);return x}

Note: We wrap tableInsert in a lambda function rather than simply passing function=tableInsert because tableInsert returns the number of rows inserted, not the updated table itself.

If we use function=tableInsert directly, the value in the dictionary would be overwritten with an integer (the row count). For example, when inserting the second record for IBM, the value would incorrectly become a number. Then, when inserting a third record, an error would be thrown because the value is no longer a table.

Initially, historyDict is empty. We use the initFunc parameter to initialize the value for a new key:

def(x){
  t = table(100:0, x.keys(), each(type, x.values()));
  tableInsert(t, x);
  return t
}

Complete code:

orders = table(`IBM`IBM`IBM`GOOG as SecID, 1 2 3 4 as Value, 4 5 6 7 as Vol)
historyDict = dict(STRING, ANY)
historyDict.dictUpdate!(function=def(x,y){tableInsert(x,y);return x}, keys=orders.SecID, parameters=orders,
            initFunc=def(x){t = table(100:0, x.keys(), each(type, x.values())); tableInsert(t, x); return t})

After execution, the contents of historyDict will be as follows:

GOOG->
Vol Value SecID
--- ----- -----
7   4     GOOG

IBM->
Vol Value SecID
--- ----- -----
4   1     IBM
5   2     IBM
6   3     IBM
